PyTorch Environment

Default environment for PyTorch

This notebook describes and creates the default PyTorch machine learning environment in Nextjournal. Check out the showcase if you want to see what the environment contains. To see how it’s built, see setup.

Nextjournal's PyTorch environment runs PyTorch v1.3.1, and is configured to use Nvidia CUDA v10.2.

Showcase

Training

Adapted from the PyTorch MNIST example. Imports:

from __future__ import print_function
import torch
import torch.nn as nn
import torch.nn.functional as F
import torch.optim as optim
from torchvision import datasets, transforms
1.2s
PyTorch Testing (Python)
Python PyTorch

Define network.

class Net(nn.Module):
  def __init__(self):
    super(Net, self).__init__()
    self.conv1 = nn.Conv2d(1, 20, 5, 1)
    self.conv2 = nn.Conv2d(20, 50, 5, 1)
    self.fc1 = nn.Linear(4*4*50, 500)
    self.fc2 = nn.Linear(500, 10)
  def forward(self, x):
    x = F.relu(self.conv1(x))
    x = F.max_pool2d(x, 2, 2)
    x = F.relu(self.conv2(x))
    x = F.max_pool2d(x, 2, 2)
    x = x.view(-1, 4*4*50)
    x = F.relu(self.fc1(x))
    x = self.fc2(x)
    return F.log_softmax(x, dim=1)
0.7s
PyTorch Testing (Python)
Python PyTorch

Train and test functions.

def train(args, model, device, train_loader, optimizer, epoch):
  model.train()
  for batch_idx, (data, target) in enumerate(train_loader):
    data, target = data.to(device), target.to(device)
    optimizer.zero_grad()
    output = model(data)
    loss = F.nll_loss(output, target)
    loss.backward()
    optimizer.step()
    if batch_idx % args.log_interval == 0:
      print('Train Epoch: {} [{}/{} ({:.0f}%)]\tLoss: {:.6f}'.format(
        epoch, batch_idx * len(data), len(train_loader.dataset),
        100. * batch_idx / len(train_loader), loss.item()))
def test(args, model, device, test_loader):
  model.eval()
  test_loss = 0
  correct = 0
  with torch.no_grad():
    for data, target in test_loader:
      data, target = data.to(device), target.to(device)
      output = model(data)
      # sum up batch loss
      test_loss += F.nll_loss(output, target, reduction='sum').item()
      # get the index of the max log-probability
      pred = output.argmax(dim=1, keepdim=True)
      correct += pred.eq(target.view_as(pred)).sum().item()
  test_loss /= len(test_loader.dataset)
  print('\nTest set: Average loss: {:.4f}, Accuracy: {}/{} ({:.0f}%)\n'.format(
    test_loss, correct, len(test_loader.dataset),
    100. * correct / len(test_loader.dataset)))
0.9s
PyTorch Testing (Python)
Python PyTorch

Set options and train.

args = type('', (), {})()
args.batch_size = 64
args.test_batch_size = 1000
args.epochs = 10
args.lr = 0.01
args.momentum = 0.5
args.no_cuda = False
args.seed = 1
args.log_interval = 10
args.save_model = True
use_cuda = not args.no_cuda and torch.cuda.is_available()
torch.manual_seed(args.seed)
device = torch.device("cuda" if use_cuda else "cpu")
kwargs = {'num_workers': 1, 'pin_memory': True} if use_cuda else {}
train_loader = torch.utils.data.DataLoader(
  datasets.MNIST('../data', train=True, download=True,
                 transform=transforms.Compose([
                 transforms.ToTensor(),
                 transforms.Normalize((0.1307,), (0.3081,))
                 ])),
  batch_size=args.batch_size, shuffle=True, **kwargs)
test_loader = torch.utils.data.DataLoader(
  datasets.MNIST('../data', train=False, transform=transforms.Compose([
                 transforms.ToTensor(),
                 transforms.Normalize((0.1307,), (0.3081,))
                 ])),
  batch_size=args.test_batch_size, shuffle=True, **kwargs)
model = Net().to(device)
optimizer = optim.SGD(model.parameters(), lr=args.lr, momentum=args.momentum)
for epoch in range(1, args.epochs + 1):
  train(args, model, device, train_loader, optimizer, epoch)
  test(args, model, device, test_loader)
if (args.save_model):
  torch.save(model.state_dict(),"/results/mnist_cnn.pt")
178.8s
PyTorch Testing (Python)
Python PyTorch
mnist_cnn.pt

Using a Pre-trained Model

Adapted from the fast-neural-style example.

Download the PyTorch example repo to get the relevant module files for the 'fast-neural-style' example. PYTHONPATH is set to the example's directory in the Runtime Settings, so import will work.

This repo is mounted by: PyTorch Testing(Change)

The pre-trained models are downloaded, saved to results, and locked. Unzip them.

wget --progress=dot:giga -O /results/saved_models.zip \
  https://www.dropbox.com/s/lrvwfehqdcxoza8/saved_models.zip?dl=1
2.6s
Python PyTorch (Bash)
saved_models.zip
unzip NJ__REF_ -d /
1.4s
PyTorch Testing (Bash in Python)
Python PyTorch

Imports.

import argparse
import os
import sys
import time
import re
import numpy as np
import torch
from torch.optim import Adam
from torch.utils.data import DataLoader
from torchvision import datasets
from torchvision import transforms
import torch.onnx
import utils
from transformer_net import TransformerNet
from vgg import Vgg16
0.7s
PyTorch Testing (Python)
Python PyTorch

The main styling function.

def stylize(args):
  device = torch.device("cuda" if args.cuda else "cpu")
  content_image = utils.load_image(args.content_image, scale=args.content_scale)
  content_transform = transforms.Compose([
    transforms.ToTensor(),
    transforms.Lambda(lambda x: x.mul(255))
  ])
  content_image = content_transform(content_image)
  content_image = content_image.unsqueeze(0).to(device)
  if args.model.endswith(".onnx"):
    output = stylize_onnx_caffe2(content_image, args)
  else:
    with torch.no_grad():
      style_model = TransformerNet()
      state_dict = torch.load(args.model)
      # remove saved deprecated running_* keys in InstanceNorm from the checkpoint
      for k in list(state_dict.keys()):
        if re.search(r'in\d+\.running_(mean|var)$', k):
          del state_dict[k]
      style_model.load_state_dict(state_dict)
      style_model.to(device)
      if args.export_onnx:
        assert args.export_onnx.endswith(".onnx"), "Export model file should end with .onnx"
        output = torch.onnx._export(style_model, content_image,
                                    args.export_onnx).cpu()
      else:
        output = style_model(content_image).cpu()
  utils.save_image(args.output_image, output[0])
0.8s
PyTorch Testing (Python)
Python PyTorch

Helper function, used with ONNX model files.

def stylize_onnx_caffe2(content_image, args):
  """
  Read ONNX model and run it using Caffe2
  """
  assert not args.export_onnx
  import onnx
  import onnx_caffe2.backend
  model = onnx.load(args.model)
  prepared_backend = onnx_caffe2.backend.prepare(model, device='CUDA' if args.cuda else 'CPU')
  inp = {model.graph.input[0].name: content_image.numpy()}
  c2_out = prepared_backend.run(inp)[0]
  return torch.from_numpy(c2_out)
0.7s
PyTorch Testing (Python)
Python PyTorch

Let's make a Euphonium look fancy.

It's fast, so we might as well run through all four models.

args = type('', (), {})()
args.content_scale = None
args.cuda = 1
args.export_onnx = ""
args.content_image =
for style in ["candy","udnie","rain_princess","mosaic"]:
	args.output_image = "/results/styled-{}.jpg".format(style)
	args.model = "/saved_models/{}.pth".format(style)
	stylize(args)
2.6s
PyTorch Testing (Python)
Python PyTorch

Setup

Build the PyTorch Environment

Install the dependencies via conda. Nvidia drivers and libraries are loaded by setting the NEXTJOURNAL_MOUNT_CUDA environment variable.

conda install -c defaults -c intel \
  mkl-include mkl-dnn \
  pyyaml typing
conda install -c pytorch cuda100 magma-cuda101
conda clean -qtipy
ldconfig
64.6s
Python PyTorch (Bash)

Install torch and torchvision via pip. This ensures conda doesn't force redundant installs of cudatoolkit and cudnn.

pip install \
  -f https://download.pytorch.org/whl/${TORCH_CUDA}/torch_stable.html \
  "torch==${TORCH_VERSION}" \
  "torchvision==${TORCHVIS_VERSION}"
37.7s
Python PyTorch (Bash)

Testing

import torch
print(torch.cuda.current_device())
print(torch.cuda.device(0))
print(torch.cuda.device_count())
print(torch.cuda.get_device_name(0))
print(torch.cuda.is_available())
print(torch.rand(100,100).cuda())
0.7s
PyTorch Testing (Python)
Python PyTorch
nvidia-smi
0.5s
PyTorch Testing (Bash in Python)
Python PyTorch
