# Iris Analysis

Iris Analysis

## Analysis with Nextjournal and R using the built-in Iris dataset

Analysis with Nextjournal and R using the built-in Iris dataset

The Iris data comes from Ronald Fisher's 1936 paper, *The Use of Multiple Measurements in Taxonomic Problems.* Four features of three different Iris species were measured and recorded. Fisher settled on a sample size of fifty for each species.

## 1. The data

1.

The data

The raw data can be viewed in a table by returning it as the final value from a cell.

`iris`

The `summary()`

function shows a few statistical measures of the data.

summary(iris)

## 2. Plotting

2.

Plotting

We'll use the plotting functionality built into R and attach the dataset to make things cleaner.

attach(iris)

Dot plot with regression line.

plot(Petal.Length, Petal.Width, col=Species, pch=19, main="Iris Data", xlab="Iris petal length", ylab="Iris petal width" ) abline(lm(Petal.Width~Petal.Length), col="red")

Scatter matrix, with color coding by species and regression lines.

par(xpd=TRUE) pairs(~Sepal.Length+Sepal.Width+Petal.Length+Petal.Width, data=iris, panel=function(x,y,...) { par(new = TRUE) plot(x,y,...) abline(lm(y~x), col="red") }, col=Species, pch=19, main="Iris Matrix", label=c("Sepal Length", "Sepal Width", "Petal Length", "Petal Width") ) legend("bottomright", fill = unique(Species), legend = c(levels(Species)), bg="white")
