MNIST Handwritten Digit Recognition in PyTorch
In this article we'll build a simple convolutional neural network in PyTorch and train it to recognize handwritten digits using the MNIST dataset. Training a classifier on the MNIST dataset can be regarded as the hello world of image recognition.
MNIST contains 70,000 images of handwritten digits: 60,000 for training and 10,000 for testing. The images are grayscale, 28x28 pixels, and centered to reduce preprocessing and get started quicker.
Setting up the Environment
We will be using PyTorch to train a convolutional neural network to recognize MNIST's handwritten digits in this article. PyTorch is a very popular framework for deep learning like Tensorflow, CNTK and Caffe2. But unlike these other frameworks PyTorch has dynamic execution graphs, meaning the computation graph is created on the fly.
Since there's already a PyTorch environment from another article, we can just transclude it and use it here.
With the imports in place we can go ahead and prepare the data we'll be using. But before that we'll define the hyperparameters we'll be using for the experiment. Here the number of epochs defines how many times we'll loop over the complete training dataset, while learning_rate and momentum are hyperparameters for the optimizer we'll be using later on.
For repeatable experiments we have to set random seeds for anything using random number generation - this means numpy and random as well! It's also worth mentioning that cuDNN uses nondeterministic algorithms which can be disabled setting torch.backends.cudnn.enabled = False.
Now we'll also need DataLoaders for the dataset. This is where TorchVision comes into play. It let's use load the MNIST dataset in a handy way. We'll use a batch_size of 64 for training and size 1000 for testing on this dataset. The values 0.1307 and 0.3081 used for the Normalize() transformation below are the global mean and standard deviation of the MNIST dataset, we'll take them as a given here.
TorchVision offers a lot of handy transformations, such as cropping or normalization.
PyTorch's DataLoader contain a few interesting options other than the dataset and batch size. For example we could use num_workers > 1 to use subprocesses to asynchronously load data or using pinned RAM (via pin_memory) to speed up RAM to GPU transfers. But since these mostly matter when we're using a GPU we can omit them here.
Now let's take a look at some examples. We'll use the test_loader for this.
Now let's go ahead and build our network. We'll use two 2-D convolutional layers followed by two fully-connected (or linear) layers. As activation function we'll choose rectified linear units (ReLUs in short) and as a means of regularization we'll use two dropout layers. In PyTorch a nice way to build a network is by creating a new class for the network we wish to build. Let's import a few submodules here for more readable code.
Broadly speaking we can think of the torch.nn layers as which contain trainable parameters while torch.nn.functional are purely functional. The forward() pass defines the way we compute our output using the given layers and functions. It would be perfectly fine to print out tensors somewhere in the forward pass for easier debugging. This comes in handy when experimenting with more complex models. Note that the forward pass could make use of e.g. a member variable or even the data itself to determine the execution path - and it can also make use of multiple arguments!
Now let's initialize the network and the optimizer.
Note: If we were using a GPU for training, we should have also sent the network parameters to the GPU using e.g. network.cuda(). It is important to transfer the network's parameters to the appropriate device before passing them to the optimizer, otherwise the optimizer will not be able to keep track of them in the right way.
Training the Model
Time to build our training loop. First we want to make sure our network is in training mode. Then we iterate over all training data once per epoch. Loading the individual batches is handled by the DataLoader. First we need to manually set the gradients to zero using optimizer.zero_grad() since PyTorch by default accumulates gradients. We then produce the output of our network (forward pass) and compute a negative log-likelihodd loss between the output and the ground truth label. The backward() call we now collect a new set of gradients which we propagate back into each of the network's parameters using optimizer.step(). For more detailed information about the inner workings of PyTorch's automatic gradient system, see the official docs for autograd (highly recommended).
We'll also keep track of the progress with some printouts. In order to create a nice training curve later on we also create two lists for saving training and testing losses. On the x-axis we want to display the number of training examples the network has seen during training.
We'll run our test loop once before even starting the training to see what accuracy/loss we achieve just with randomly initialized network parameters. Can you guess what our accuracy might look like for this case?
Neural network modules as well as optimizers have the ability to save and load their internal state using .state_dict(). With this we can continue training from previously saved state dicts if needed - we'd just need to call .load_state_dict(state_dict).
Now for our test loop. Here we sum up the test loss and keep track of correctly classified digits to compute the accuracy of the network.
And that's it. With just 3 epochs of training we already managed to achieve 97% accuracy on the test set! We started out with randomly initialized parameters and as expected only got about 10% accuracy on the test set before starting the training.
Again running a training loop should immediately pick up the training where we left it. To check on that let's simply use the same lists as before to keep track of the loss values. Due to the way we constructed the test counter for the number of training examples seen we manually have to append to it here.
That still looks like a rather smooth learning curve just as if we initially would've trained for 8 epochs! Remember that we just appended values to the same lists starting from the 5th red dot onward.
From this we can conclue two things:
1. Continuing from the checkpointed internal state worked as intended.
2. We still don't seem to run into overfitting issues! It looks like our dropout layers did a good job regularizing the model.
In summary we built a new environment with PyTorch and TorchVision, used it to classifiy handwritten digits from the MNIST dataset and hopefully developed a good intuition using PyTorch. For further information the official PyTorch documentation is really nicely written and the forums are also quite active!
